P8 RGBProgrammable Scrolling LED Sign With Iron Steel Cabinet , Multi Language

Product Details:

Place of Origin: China
Brand Name: Mega
Certification: UL CE ROHS ISO ETL SGS SAA Fcc EMC
Model Number: P10 DIP RGB LED Sign

Payment & Shipping Terms:

Minimum Order Quantity: 1 PCS / 1 Unit
Price: Negotiation
Packaging Details: Carton box or Wooden case
Delivery Time: 3-4 work days
Payment Terms: L/C, T/T, Western Union, Paypal, Credit Card, MoneyGram, VISA
Supply Ability: 5,000 pcs per month
Detailed Product Description
Display Color: 1R1G1B / Red / Green / Blue / Yellow Working Temp: -20 Degree To +60 Degree
Certificate: UL CE, RoHS, FCC, ISO Etc. Display Function: Video , Text, Messages, Graphi
Display Languages: World Language Working Voltage: AC220V±10%50Hz Or AC110±10%60Hz
LED Display Useage: Front Side: IP65, Backside: IP54 Led Display Frame Material: Iron Steel Cabinet
Brightness: 8000nits


P8 RGB Programmable LED Message Board , 3G / WIFI Wireless Control Custom LED Sign



Product Description:

These are very easy to program with software we provide. Data can be transferred through USB or LAN . It constantly displays Full color Logos , Videos, Text , Neon sign features, Images , time , Animations, stopwatch ,countdown with hundred of special effects . You can add any image or logo of your choice.

Our 1/4 duty module provides a sign that is up-to 30% brighter than 1/8 duty sign that you see from other suppliers.

1. Use LAN option and no need to go outside. Sit in your office and control sign up to 100 meter away.

2. Schedule the messages , just set the time at which you want to display the message and feel free. No need to update same events again and again.

3. Auto On / Off option .

4. Heavy duty brackets & screws

5. User manual , video tutorial and online technical support.

6. Fully accessible rare panel for easy repairs





LED moving sign introduction

Multi language: English/Spanish/Russia/Inter.char.set…..

Display one line/two lines/three lines/four lines English char.

  1. Able to show text, graphics and animation.
  2. Programmable via either remoter or PC.
  3. Port 232/485 communication.
  4. 25 actions (Snow, Spray, Twinkle, Rotate, Scroll, Star Burst, Wipe, Interlock……)
  5. All to run, Auto action, Auto color, Auto center.
  6. Fonts in Block(scans serif),decorative(serif),upper/lower, slim/wide, double.
  7. Build in Clock, Temperature, Brightness sensor.
  8. Auto on /off and time scheduling.
  9. 4/8 or 16 class Brightness.
  10. Full Screen Edit Software(SignMan). Max.512 frames stored in flash memory.
  11. Wide range voltage, DC9-30V or AC110V/220V .



Technology Specifications:

Item P8 outdoor full color led sign display
LED chip Epistar/Silan
Physical Pixel Pitch 8mm
Physical Pixel Density 15,625dots/m2
Pixel composition 1Red, 1Green,1Blue
Moduel Size 256*128mm, 320mmx160mm
Moduel resolution 40*20dots
Cabinet thickness < 170 mm
Bracket of cabinet Easy to install onto the LED cabinet and uninstall .
Brightness ≥ 7000nits
Colors 16.7million
Viewing angle Horizontal ≥120°, Vertical : ≥ 90°
Viewing distance 6m-300m
Soft Rubber Mask To protect player and LED display itself .
Scan frequency ≥1200 Hz
There will be one receive card in each cabinet
sparked .Also it is very easy to move and connetct
Video Frame Rate ≥150 fps
Color temperature 6500°K to 9500°K adjustable
Control method Controlled by PC, synchronous display
Life span( half brightness) ≥100,000 hours
Weight 30-60Kg /sqm
IP rate IP65 ( front side and rear side)
Average power consumption 300W/sqm



P8 digital led sign display function introduction:

1) High intensity and can be adjusted, so can meet the request of the customers according the application environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light.
3) Big viewing angle to 120 degree at horizontal line, 90 degree at vertical line, you can see at every angle at this range, high brightness, high resolution, clear and non-flash screen image, long service life.

Products Advantages:
1) Price: we have the best competitive price at the market, also have the same even better quality.
2) Quality: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
3) Service: 5 years warranty.

P8 RGBProgrammable Scrolling LED Sign With Iron Steel Cabinet , Multi LanguageP8 RGBProgrammable Scrolling LED Sign With Iron Steel Cabinet , Multi Language







P8 RGB Programmable LED Message Board , 3G / WIFI Wireless Control Custom LED Sign
